Product Description
Monel 400 is a corrosion-resistant alloy with the largest dosage, the most wide range of uses, and excellent comprehensive properties. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas media, as well as excellent corrosion resistance against hot concentrated alkali liquid. It is also resistant to corrosion from neutral solutions, water, seawater, atmosphere, organic compounds, etc. An important feature of this alloy is that it generally does not produce stress corrosion cracking aside from good cutting performance. Monel 400 bars are commonly adopted in many corrosive applications, particularly in the marine and chemical industries. Monel 400 can be easily machined through conventional machining operations as a relatively soft material suitable for thermoforming into almost any shape.


Product Parameters

Product Name

Monel 400 Bar

Specification Range

Round Bar

4mm-500mm

Hexagon Bar

18mm-57mm (11/16″ to 2-3/4″)

Square Bar

18mm-47mm (11/16″ to 1-3/4″)

Flat Bar

1/2 "to 10", Thickness: 2mm-150mm, Can provide customized

Length

1-6 meters, Length can be customized

Standard

ASTM, AISI, JIS, GB, DIN, EN, etc.

Surface

Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc.

Certificate

ISO, SGS, BV

Production Technology

Hot Rolling, Cold Rolling


Chemical Composition

Nickel, minACopperlron, maxManganese, maxCarbon, maxSilicon, maxSulfur, max
63.0%28.0% - 34.0%2.5%2.0%

0.3%

0.5%

0.024%


Mechanical Properties

Tensile Strength (ksi)

0.2% Yield Strength (ksi)

Elongation% in 2 inches

85

35

30


Physical Performance


Units

Temperature in°C

Density

8.14 g/cm³

Room

Specific Heat

0.105 Kcal/kg.C

Room

Melting Range

1370-1400°C

-

Modulus of Elasticity

196 KN/mm²

20°

Electrical Resistivity

113 µΩ.cm

25°

Coefficient of Expansion

14.1 µm/m °C

25 - 100°

Thermal Conductivity

11.1 w/m-° K

25°


Scope of Application

Used in marine engineering, chemical and hydrocarbon processing equipment, gasoline tanks and fresh water tanks, crude oil distillers, degassing heaters, boiler feed water heaters and other heat exchangers, valves, pumps, shafts, accessories and fasteners, Industrial heat exchangers, chlorinated solvents, crude oil distillation columns, etc.
