Product Description
Monel 400 is a corrosion-resistant alloy with the largest usage, the widest range of uses, and excellent comprehensive properties. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas media, and also has excellent corrosion resistance against hot concentrated alkali liquid. It is also resistant to corrosion from neutral solutions, water, seawater, atmosphere, organic compounds, etc. An important feature of this alloy is that it generally does not produce stress corrosion cracking and has good cutting performance. Monel 400 plate is widely used in many corrosive applications, particularly in the marine and chemical industries. Monel 400 can be easily machined through conventional machining operations. It is a relatively soft material suitable for thermoforming into almost any shape.


Product Parameters

Product Name

Monel 400 Plate

Thickness

0.3mm-200mm

Length

2000mm, 2438mm, 3000mm, 5800mm, 6000mm, 12000mm, etc.

Width

40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.

Standard

ASTM, AISI, JIS, GB, DIN, EN, etc.

Surface

BA, 2B, NO.1, NO.4, 4K, HL, 8K, etc.

Certificate

ISO, SGS, BV

Production Technology

Hot Rolling, Cold Rolling


Chemical Composition

Nickel, minACopperlron, maxManganese, maxCarbon, maxSilicon, maxSulfur, max
63.0%28.0% - 34.0%2.5%2.0%

0.3%

0.5%

0.024%


Mechanical Properties

Condition (Temper)Tensile Strength, min, psi (MPa)

Yield StrengthA

(0.2 % offset), min, psi (MPa)

Elongation

in 2 in. or

50 mm, or

4D, min,%

Rockwell Hardness

(B Scale)b,c

Hot-Rolled Plate
Annealed70000 (485)28000 (195)35-
As-RolledD,E75000 (515)40000 (275)25-
Hot-Rolled Sheet
Annealed70000 (485)28000 (195)35-
Cold-Rolled Sheet
Annealed70000 - 85000 (485 - 585)28000 (195)35-
Quarter-Hard---73 - 83
Half-Hard---82 - 90
Hard100000 (690)90000 (620)2-
Cold-Rolled Strip
Annealed70000 - 85000 (485 - 585)F28000 (195)35F-
Skin Hard---68 - 73
Quarter-Hard---73 - 83
Half-Hard---82 - 90
Three-Quarter-Hard---89 - 94
Hard100000 (690)F90000 (620)F2F-
Spring Temper---98 min


Physical Performance

Physical Performance

Units

Temperature in°C

Density

8.14 g/cm³

Room

Specific Heat

0.105 Kcal/kg.C

Room

Melting Range

1370-1400°C

-

Modulus of Elasticity

196 KN/mm²

20°

Electrical Resistivity

113 µΩ.cm

25°

Coefficient of Expansion

14.1 µm/m °C

25 - 100°

Thermal Conductivity

11.1 w/m-° K

25°


Scope of Application

Used in marine engineering, chemical and hydrocarbon processing equipment, gasoline tanks and fresh water tanks, crude oil distillers, degassing heaters, boiler feed water heaters and other heat exchangers, valves, pumps, shafts, accessories and fasteners, Industrial heat exchangers, chlorinated solvents, crude oil distillation columns, etc.
