Product Description

Nickel Alloy 200 Pipe is a commercially pure (99.6% min) wrought nickel pipe known for its excellent mechanical properties and exceptional resistance to a wide range of corrosive environments. Its high nickel content makes it particularly effective in maintaining corrosion resistance in reducing atmospheres, caustic alkalies, and various organic and inorganic compounds. This alloy is the material of choice for applications requiring high thermal, electrical, and magnetostrictive properties.

Product Parameters

Product Name		Nickel Alloy 200 Pipe
Outer Diameter	Round Pipe	4mm-200mm
	Square Tube	1010mm-100100mm
	Rectangular Tube	1020mm-50100mm
Wall Thickness		0.6mm-6.0mm
Length		1-6 meters, Length can be customized
Standard		ASTM, AISI, JIS, GB, DIN, EN, etc.
Surface		Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc.
Certificate		ISO, SGS, BV
Production Technology		Hot Rolling, Cold Rolling

Chemical Composition

Gread	C	Si	S	Mn	Fe	Ni	Cu
Alloy 200	0.15 max	0.35 max	0.01 max	0.35 max	0.4 max	99.0 min	0.25 max

Mechanical Properties

Tensile Strength (ksi)	0.2% Yield Strength (ksi)	Elongation% in 2 inches
55	15	35

Physical Performance

	Units	Temperature in°C
Density	8.89 g/cm³	Room
Specific Heat	0.108 Kcal/kg.C	Room
Melting Range	1435-1446°C	-
Modulus of Elasticity	205 KN/mm²	Room
Electrical Resistivity	9.6 µΩ.cm	20°
Coefficient of Expansion	13.3 µm/m °C	20 - 100°
Thermal Conductivity	70.3 w/m-° K	20°
